舞美租赁屏 TOA960 系列技术参数 | ||||||
使用环境 | 户内 | 户外 | ||||
产品型号 | TOA960-2.5 | TOA960-5 | TOA960-5H | TOA960-6.6H | TOA960-8H | TOA960-10H |
像素间距 | 2.5mm | 5mm | 5mm | 6.67mm | 8mm | 10mm |
像素构成 | SMD2020 | SMD2020 | SMD2727 | SMD3535 | SMD3535 | SMD3535 |
像素密度 | 160000dot/m2 | 40000dot/㎡ | 40000dot/㎡ | 22500dot/ m2 | 15625dot/ m2 | 10000dot/㎡ |
模组尺寸 | 320x160mm | 320x160mm | 320x160mm | 320x160mm | 320x160mm | 320x160mm |
模组分辨率 | 128x64dot | 64x32dot | 64x32dot | 48x24dot | 40x20dot | 32x16dot |
箱体尺寸 | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 960x960mm |
箱体分辨率 | 384x384dot | 192x192dot | 192x192dot | 144x144dot | 120x120dot | 96x96dot |
重量 | 2Okg/pcs | 2Okg/pcs | 28kg/pcs | 28kg/pcs | 28kg/pcs | 28kg/pcs |
防水等级 | IP40 | IP40 | IP65/43 | IP65/43 | IP65/43 | IP65/43 |
扫描方式 | 32S | 16S | 8S | 6S | 5S | 4S |
亮度水平 | >900CD/㎡ | >800CD/ ㎡ | >5500CD/㎡ | >5500CD/㎡ | >4500CD/㎡ | >4500CD/㎡ |
可视角度 | 120° | 120° | 120° | 120° | 120° | 120° |
观看距离 | >2.5m | >5m | >5m | >7m | >7m | >7m |
灰度等级 | Mbit | Mbit | Mbit | Mbit | Mbit | Mbit |
色彩种类 | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M |
最大功率 | 950W/m2 | 850W/m2 | 1200W/m2 | 850W/m2 | 800W/m2 | 700W/m2 |
平均功率 | 315W/m2 | 280W/m2 | 400W/m2 | 280W/m2 | 240W/m2 | 210W/m2 |
刷新率 | >1920HZ | >2880HZ | >2880HZ | >2880HZ | >2880HZ | >2880HZ |
亮度调节 | 0-100 levels adjustable | |||||
控制方式 | Synchronous display with control PC by DVI | |||||
支持信号输入类型 | Composite,S-Vido,Component,VGA}DVI,HDMI,HD_SDI | |||||
输入电源 | AC100/240 50/60HZ | |||||
工作温度 | -20°C~+50°C | |||||
工作湿度 | 10-90% RH | |||||
工作寿命 | 100,000hours |
